Preliminary CSA O86 workflow for hold-downs, ties, hangers, straps, screw/bolt groups, and anchor demand.
Preliminary CSA O86 based wood connection workflow for hold downs, uplift ties, joist hangers, collector straps, wood screw groups, bolt groups, and anchor to concrete review placeholders. Compares factored demands to source tagged connector or fastener capacities, tracks installation requirements, flags missing data, and exports structured handoff results.
Placeholder connector capacities are not final design values. Full manufacturer lookup, proprietary interaction equations, eccentric fastener group design, concrete anchor design, fire design, and seismic capacity protected connection design are not implemented in this phase.
Use for preliminary connection demand tracking, review planning, and source controlled connector selection only. Verify all capacities, fastener schedules, installation requirements, anchorage, edge distances, and manufacturer data before project use.
